Free Installation Training Included 1-Year Warranty Spare Parts PackageThe QT4-24 semi-automatic block making machine is a mechanical vibration type block machine engineered for entrepreneurs and small-to-medium brick plants seeking an affordable entry point into concrete block production. Designed by Dongyue Machinery with over 30 years of manufacturing expertise, the QT4-24 balances low capital investment with reliable, high-yield output — making it one of the most popular starter machines in emerging markets across Africa, Southeast Asia, and South Asia.
At the heart of the QT4-24 is a dual-motor vibration system — two 5.5 kW bottom vibration motors paired with a 3 kW top mold vibration motor — generating 35.5 kN of excitation force at 4,200 rpm. This table-mold synchronous vibration technology ensures that concrete is fully liquefied and compacted within seconds, producing blocks with uniform density, precise dimensions, and compressive strength suitable for load-bearing walls.
Unlike fully manual machines that demand heavy physical labor, the QT4-24 features electric mold sliding and automatic material feeding, completing the material distribution cycle in a single pass. This semi-automatic design reduces the crew to just 5 workers — one for the mixer, one for the main machine, one for material loading, and two for brick collection — significantly lowering ongoing labor costs while keeping the initial investment within reach of first-time buyers.
With a total power consumption of just 10.58 kW, the QT4-24 is particularly well-suited for regions where electrical infrastructure is limited or expensive. The machine's compact footprint (3,500 × 1,350 × 2,650 mm) and modest weight (2.95 tons) mean it can be installed in existing structures without major civil engineering work, further reducing the total project cost.
| Technical Parameter | Standard Value (QT4-24) |
|---|---|
| Main Vibration Motors | 5.5 kW × 2 (Lower) + 3 kW (Upper) |
| Total System Power | 13.45 kW |
| Molding Cycle | 24 Seconds |
| Pallet Size | 850 × 550 × 25 mm |
| Machine Mass | 1,560 kg |
| Control Method | Button-Controlled / Semi-Automatic |
| Block Type | Size (L×W×H) | Qty / Cycle | Daily Output |
|---|---|---|---|
| Hollow Block | 400 × 200 × 200 mm | 4 pcs | 2,880 - 3,600 pcs |
| Standard Brick | 240 × 115 × 53 mm | 24 pcs | 28,800 - 34,560 pcs |
| paver Brick | 200 × 100 × 60 mm | 4 pcs | 13,440 - 20,160 pcs |
| Brick | 200 × 163 × 60 mm | 8 pcs | 7,680 - 11,520 pcs |
DONGYUE changed the rules of the game for our decoration company's brick manufacturing. Their reliable after-sales service ensures that our products satisfy customers.
"The dual-line QT6-15 setup from Dongyue transformed our capacity. We now produce twice the blocks of a single line from one site, and because the two lines share batching and control, we use far less land and a much smaller crew than if we had built two separate plants. In the UAE's land- and labor-cost environment, that efficiency is exactly what made the investment pay back quickly. Dongyue's engineers handled the layout, installation, and training professionally — the plant has run reliably since day one, and we would recommend them to any producer planning to scale up."
Now we make our own concrete bricks and hollow blocks right here in India, with steady density and sizes our clients trust — and the machine is so simple my local crew runs it without fuss. The line paid for itself faster than we budgeted, and we finally say yes to the housing and infrastructure contracts we used to turn away."
Awesome brick machine! Super strong vibration makes really dense blocks. Totally worth it for the price
Easy to run, low maintenance, and the price is great for starting out.!
" We were buying from many small yards and importers, and our own output was never steady. Now we make our own hollow blocks and standard bricks here in Zimbabwe on a machine that runs on normal power and a small team. The blocks are consistent, our clients trust the dimensions, and the line paid for itself faster than we expected. We finally take the housing and municipal orders we used to turn away."
"Before the QT8-15, we were buying from small yards and importers, and our own output was never steady. Now we make our own hollow blocks, standard bricks and colored pavers here in Guinea-Bissau on one fully-automatic machine. The blocks are consistent, our clients trust the dimensions, and the colored pavers opened urban and municipal orders we could never serve before. The line paid for itself faster than we expected, and we finally take the housing and public-works contracts we used to turn away."
5-10 kWh/1,000 blocks. We’ll share a detailed cost estimate.
Free for faulty parts (excluding wear from improper use).
For making 400*200*200， 8 inches hollow block , Varies by model: 2000-3,000 (small) / 5,000-15,000 (medium ) blocks/day.20000-35000 (High). We’ll match your target.
Standard blocks (hollow/solid/paving) + custom molds for your dimensions.we can send you block sample
Shipping (by size/address) isn’t included; we can bundle it with installation if needed.
